DOUBLE COLUMN LIFTING MACHINE

HL-4000

2019-12-06 14:28:27

Technical Parameter
Capacity-----------------------------------------------------4000kg
Lifting height----------------------------------------------1600mm
Min height---------------------------------------------------240mm
Lifting time-------------------------------------------------40s-50s
Runway width----------------------------------------------520mm
Runway height-------------------------------------------4200mm
Voltage--------------------------------------------------220V/380V
Motor power-------------------------------------------------2.2KW
Overall height---------------------------------------------2120mm
 power supply----------------------------220v/240v/380v/415v
Rated oil pressure-----------------------------------------18Mpa
Weight------------------------------------------------------1175KG
